Ubiquiti Wave Pico (Wave-Pico)
| Hersteller-SKU | Wave-Pico |
|---|---|
| EAN | 810084693872 |
| Hersteller | Ubiquiti |
| Stück in Sammelverpackung | 8 |
Lightweight, compact design of a (PtMP) CPE device operating in the 60 GHz range with Wave Technology software.
Ubiquiti Wave Pico (Wave-Pico)
Lightweight, compact design of a (PtMP) radio device operating in the 60 GHz range with Wave Technology software.
Ubiquiti Wave Pico can connect to the access points Ubiquiti Wave AP, Wave AP Micro and provide a total throughput up to 2 Gb/s (1 Gb/s duplex). Wave Pico is equipped with a high-performance 5 GHz backup radio that ensures an uninterrupted connection and a Bluetooth radio for simply setup using the UISP Ubiquiti mobile app.
A backup 5 GHz radio can be used in case the main connection fails. Wave Pico has 1x Gigabit Ethernet port and its maximum wireless connection speed is 2 Gb/s.
Ubiquiti UISP Wave Pico is powered by passive PoE 48 V DC (power supply included) or can be powered by a Ubiquiti UISP router or switch. Ubiquiti Wave Pico is designed to create efficient point-to-multipoint connections between buildings at link distances of up to 0.9 km (with Wave AP Micro) and up to 1.3 km (with Wave AP). The set includes a pole holder.
Main features:
- operation in the 60 GHz band
- max wireless throughput 2 Gbps (1 Gbps duplex)
- link range up to 0.9 km (with Wave AP Micro) and up to 1.3 km (with Wave AP)
- 1x Gigabit Ethernet port
- backup radio 5 GHz
- managed by Bluetooth
- router and bridge mode support
- powered via passive PoE 48V
- managed via the UISP application
Technical Specifications:
| Mechanisch | |
|---|---|
| Abmessungen | Ø152.1 x 55.8 mm (Ø6 x 2.2") |
| Gewicht | Without mount: 347 g (12.2 oz) With mount: 409 g (14.4 oz) |
| Material des Gehäuses | UV stabilized polycarbonate |
| Material montieren | UV stabilized polycarbonate |
| Durchmesser der Masthalterung | 20 to 53.1 mm (0.8 to 2.1") on pipe outer diameter |
| Wind loading | 31.3 N at 200 km/h (7 lbf at 125 mph) |
| Wetterschutz | IPX6 |
| Hardware | |
| Prozessor | Dual-core ARM® Cortex®-A53 at 1 GHz |
| Speicher | DDR3L 512 MB |
| Schnittstelle zur Vernetzung | (1) GbE RJ45 port |
| Max. Leistungsaufnahme | 10W |
| Macht-Methode | Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8 -) Passive PoE 2-pairs (4, 5+; 7, 8 -), for 44–54V DC only |
| Stromversorgung | 48V DC, 0.5A gigabit PoE adapter (Included) Can be powered by a UISP Router or UISP Switch |
| Unterstützter Spannungsbereich | 44–54V DC 22–27V DC |
| GPS | No |
| Schaltfläche | Factory reset |
| LEDs | Power, Ethernet, link |
| Betriebstemperatur in der Umgebung | -40 to 60° C (-40 to 140° F) |
| Luftfeuchtigkeit in der Betriebsumgebung | 5 to 95% noncondensing |
| Zertifizierungen | FCC, IC, CE |
| Software | |
| Betriebsart | PtMP station, PtP |
| Ubiquiti specific features | Wave AI, discovery protocol |
| Dienstleistungen | UISP, ping watchdog, NTP client, SNMP |
| Werkzeuge | Antenna alignment, discovery utility, ping, trace route, speed test |
| Netzwerk | Bridge/Router* mode *Router is available in PtMP station mode only. |
| Anforderungen an die Bewerbung | UISP web: Version 2.4.61 and later UISP mobile iOS™: Version 2.32.0 and later UISP mobile Android™: Version 2.31.9 and later |
| System | |
| Gesamtdurchsatz | 2 Gbps (1 Gbps duplex) |
| Maximale Reichweite | Up to 1.3 km (Wave AP) Up to 0.9 km (Wave AP Micro) |
| Verschlüsselung | WPA2-PSK (AES) |
| RF | |
| Betriebsfrequenz* | 57–71 GHz *Depends on regulatory region. |
| Channel bandwidth | 2160, 1080 MHz |
| Betriebskanäle* | 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region. |
| Modulation | 16QAM, QPSK |
| Antennengewinn | 27.7 dBi |
| Polarisierung | Vertically linear |
| Strahlbreite | Azimuth: 3 dB 6° Elevation: 3 dB 6° |
| Ersatz-RF | |
| WiFi-Standard | 802.11ax (WiFi 6) |
| Betriebsfrequenz* US/CA Weltweit |
U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz 5180 - 5875 MHz *Depends on regulatory region. |
| Channel bandwidth | 20, 40, 80 MHz |
| Modulation | BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6) |
| Antennengewinn | 9 dBi |
| Polarisierung | Dual-linear |
| Strahlbreite | Azimuth: 3 dB 50° Elevation: 3 dB 50° |
| Cross-pol isolation | 15 dB |
| LEDs | |
| Strom | Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress |
| Ethernet | Flashing blue: Ethernet traffic detected |
| Links | White: 5 GHz link Blue: 60 GHz link |
| Hersteller-SKU | Wave-Pico |
|---|---|
| EAN | 810084693872 |
| Hersteller | Ubiquiti |
| Stück in Sammelverpackung | 8 |
| GPSR kontakt | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
