Ubiquiti Enterprise NVR Core - 16-bay 3U recorder for up to 300 4K cameras (ENVR-Core)
| Manufacturer SKU | ENVR-Core |
|---|---|
| Manufacturer | Ubiquiti |
The Ubiquiti Enterprise NVR Core is a 3U (16 x 2.5"/3.5") NVR powered by a 128-core ARM processor. It supports up to 500 HD cameras or 300 4K cameras, offering 25G SFP28 bandwidth, hot-swappable redundant power, and expandability up to 48 drives (NDAA compliant).
Accessories and add-ons:
Ubiquiti Enterprise NVR Core – 3U Surveillance Recorder for Enterprise Systems
Ubiquiti Enterprise NVR Core (ENVR-Core) is a network recorder designed to centralize and support extensive IP surveillance infrastructures and access control systems in corporate environments. The device's computing foundation is a 128-core ARM v8.2 processor (clocked at 2.6 GHz), supported by 64 GB of RAM. This hardware configuration allows for the smooth management and recording of video streams from up to 300 4K cameras, 400 2K cameras, or as many as 500 Full HD cameras. The recorder natively supports the UniFi Protect and UniFi Access platforms, enabling simultaneous operation of over 300 access controllers (Access Hubs).
The 3U design, designed for mounting in a standard 19" rack, offers 16 built-in bays for HDDs or SSDs in 2.5" and 3.5" formats. The device offers scalable data storage – thanks to the built-in two SFF-8644 expansion ports (with 24G bandwidth), administrators can connect external disk modules, increasing the total system capacity to 48 supported drives. Network connectivity is provided by two high-performance SFP28 interfaces (compatible with 25G/10G/1G standards) and one Gigabit Ethernet RJ45 port.
Power security is ensured by two Redundant 550W power supplies (CRPS standard), supporting hot-swap, allowing for their replacement without interruption to device operation. The housing is made of cold-rolled galvanized steel (SGCC) and certified for compliance with NDAA guidelines confirm the industrial nature of the solution, ready for deployment in high-security facilities.
Key Features:
-
Processor and Memory: 128-core ARM v8.2 (2.6 GHz), 64 GB RAM.
-
Video Performance: Supports up to 500 HD cameras / 400 2K cameras / 300 4K cameras.
-
Data Space: 16x 2.5/3.5" HDD/SSD bays; Expandable to 48 drives in total.
-
Expansion ports: 2x SFF-8644 (24G) connectors for external arrays.
-
Network interfaces: 2x 25G SFP28 port, 1x 1GbE RJ45 (MGMT) port.
-
Power and Redundancy: 2x hot-swappable 550W CRPS (100–240V).
-
Chassis: 3U 19' rack mount (SGCC steel).
-
Management: Supports UniFi Protect and UniFi Access systems (300+ hubs).
-
Certifications: NDAA Compliant.




Technical Specifications
| Supported Cameras | (500) HD, (400) 2K, (300) 4K |
| Supported Access Hubs | 300+ |
| Disk Capacity (Bays) | (16) 3.5" Drive Bays |
| Data Protection | Yes |
| Vantage Point | Yes |
| Network Interfaces | (2) 25G SFP28 ports (25G/10G/1G) (1) GbE MGMT RJ45 port (1G/100M) |
| Expansion Ports | (2) SFF-8644 ports (24G) |
| Power Redundancy | Yes |
| Control Support Access | Yes |
| Management Apps | UniFi Protect, UniFi Access |
Device |
|
| Disk Support | (16) 2.5/3.5" HDD/SSD Bays (2) Expansion Ports, Support for up to 48 HDD/SSD Drives |
| Processor | 128-core Arm® v8.2 clocked at 2.6 GHz |
| RAM | 64 GB |
| Management | Ethernet, Bluetooth |
| Front Panel | Support for UACC-3U-Bezel-Lite (included) |
| LED Indicators | SFP28, HDD, System, Expansion Port, CRPS |
| Compatible with NDAA | Yes |
| Certifications | CE, FCC, IC |
Software |
|
| Mobile App Requirements | UniFi Protect iOS™: version 3.3.0 and later UniFi Protect Android™: version 3.2.0 and later |
Power Supply |
|
| Max. Drive Power Budget | 313 W |
| Max. Power Consumption | 237 W (excluding HDD power) |
| Power Supply Method | (2) AC Inputs, 100–240V, max. 7A, 50/60Hz (redundant, hot-swappable) |
| Power Supply | Hot-swappable 550W CRPS |
Other |
|
| Dimensions | 481.4 x 550 x 132 mm (19 x 21.7 x 5.2") |
| Chassis Form Factor | Rack Mount (3U) |
| Weight | Without Rails: 20.5 kg With Rails: 23.4 kg |
| Chassis Material | SGCC Steel |
| Mounting Material | Aluminum |
| Mounting Rails | Supports 19" four-post racks, square holes (9.5 x 9.5 mm), depth 600–1066 mm |
| Ambient Operating Temperature | 10 to 35° C (50 to 95° F) |
| Ambient Operating Humidity | 20 to 90% (non-condensing) |








Ubiquiti Enterprise NVR Core – Frequently Asked Questions (FAQ)
Yes. The Enterprise NVR Core system supports UniFi Protect devices and functions, e.g. AI Key, AI Port, SuperLink Gateway and Protect Viewport.
Yes. Enterprise NVR Core supports UniFi Access, allowing you to manage cameras and door access from a single device.
Yes. Enterprise NVR Core can work without access to an external network. However, a UniFi or third-party gateway or Layer 3 switch is required to assign IP addresses to cameras.
Yes. Enterprise NVR Core supports seamless integration with third-party ONVIF-compliant cameras, enabling smooth and easy migration of existing security systems to UniFi Protect.
Enterprise NVR Core supports RAID 5, RAID 6, and RAID 10 with optional hot spares to protect surveillance footage from data loss.
Enterprise NVR Core supports a single drive (HDD or SSD) in a 2.5" or 3.5" format with the following requirements:
- Minimum capacity: 1 TB
- Must be CMR (Conventional Magnetic Recording)
- 7200 RPM drives required
Yes. The Enterprise NVR Core includes two (2) Mini-SAS HD ports designed for storage expansion, enabling longer retention periods for large camera counts.
The management port provides dedicated recovery access for maintenance and troubleshooting, including UniFi Recovery mode.
