Mikrotik Chateau LTE12 (RBD53G-5HacD2HnD-TC&EG12-EA)
| Manufacturer SKU | RBD53G-5HacD2HnD-TC&EG12-EA |
|---|---|
| EAN | 4752224003546 |
| Manufacturer | Mikrotik |
| PCS in collective packaging | 20 |
Chateau LTE12 (RBD53G-5HacD2HnD-TC&EG12-EA)
Ultimate home AP with LTE support
Let’s face it – most of the standard issue access points can’t really satisfy the extremely diverse client base – they either lack features, users want more speed and higher gain, the price is too high or they look weird. We decided to take all the aspects that are important for most home users and create a single device that will make them happy – this is the MikroTik Chateau.
It is a high-speed, dual-band home access point with CAT12 LTE – for really fast Internet anywhere, anytime. But LTE is not the only option – Chateau also features 5 x Gigabit Ethernet ports and a full size USB port.
Perfect for busy homes
Strong dual-chain dual-band 2.4/5 GHz wireless for concurrent coverage will solve most interference issues in a crowded environment. For example, a client can simultaneously use the 2.4 GHz channel for all household mobile devices and reserve the 5 GHz channel for tasks that are sensitive to packet loss – such as streaming high-quality videos.
Built with security in mind
Not only our RouterOS software comes with robust security options, we also focus on the production security. There is no outsourcing, every device is assembled in our premises and all the components come from reputable, trusted partners – such as Qualcomm. We cooperate with European law-makers and work hard to ensure full compliance with all the necessary safety policies. MikroTik is all about smooth, long-term cooperation without surprises.
Enjoy all the benefits of LTE Category 12 networking!
Reach speeds of up to 600 Mbps with carrier aggregation, as CAT12 allows devices to use three bands at the same time. That is a huge advantage when there are a lot of LTE users in the area. Chateau LTE12 provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside. Depending on the service provider, we have seen Internet speed doubling in rural areas after switching to carrier aggregation, so there is no need to wait for cable network expansions.
Technical Specifications:
| CPU | 4 core IPQ-4019 716 MHz |
| RAM | 256 MB |
| Storage | 16 MB flash |
| 10/100/1000 Ethernet ports | 5 |
| Wireless | 2.4 GHz 802.11b/g/n dual-chain, 5 GHz 802.11a/n/ac dual-chain |
| Wireless regulations | Specific frequency range will be limited by country regulations |
| Wireless antenna max gain | 2.5 dBi |
| LTE category | 12 (600 Mbps Downlink, 150 Mbps Uplink), the LTE chip is built-in, 4x4 MIMO LTE support |
| LTE antenna max gain | 4 dBi, option for external SMA conector |
| LTE bands | 1/3/5/7/8/20/28/38/40/41 |
| LTE max speed | 600 Mbps |
| LTE carrier aggregation | Yes |
| Antenna beam width | 360° |
| Supported input voltage | DC jack 12 - 28 V |
| Dimensions | 240 x 156 x 44 mm |
| Operating temperature | -40°°C .. +70°C |
| Operating system | RouterOS 7.0 (compatible only with v7 and above) |
| Micro SIM slots | 1 |
| USB port | 1 USB 2.0 port type A |
| Max power consumption | 23 W |
LTE model specifications
| Downlink (DL) / Uplink (UL) | 256 QAM / 64 QAM |
| LTE (FDD) bands | 1(2100)/3(1800)/5(850)/7(2600)/8(900)/20(800)/28(700) |
| LTE (TDD) bands | 38(2600)/40(2300)/41(2600) |
| WCDMA bands | 1 (2100)/3(1800)/5(850)/8(900) |
| Manufacturer SKU | RBD53G-5HacD2HnD-TC&EG12-EA |
|---|---|
| EAN | 4752224003546 |
| Manufacturer | Mikrotik |
| PCS in collective packaging | 20 |
| GPSR contact | Mikrotikls SIA Unijas iela 2, LV-1039 Riga, Latvia support@mikrotik.com |
