Mikrotik hAP ax3 (C53UiG+5HPaxD2HPaxD)
| Manufacturer SKU | C53UiG+5HPaxD2HPaxD |
|---|---|
| EAN | 4752224007940 |
| Manufacturer | Mikrotik |
| PCS in collective packaging | 10 |
WiFi 6 MikroTik hAP ax3 router (C53UiG+5HPaxD2HPaxD)
MikroTik hAP ax3 is a wireless router compatible with WiFi 6. The manufacturer has equipped it with an efficient quad-core ARM processor clocked at 1.8GHz, 1GB RAM and 128MB of NAND persistent memory. With this specification, the device will work well not only in typical home applications, but will also meet the expectations of more advanced users who require complex firewall rules, dynamic routing or maintaining multiple VPN connections at the same time (built-in hardware cryptographic accelerator). hAP ax3 has two radio interfaces operating simultaneously in the 2.4GHz and 5GHz bands using 2x2 MIMO antennas. Compatibility with the latest WiFi standard - 802.11ax - means that the bandwidth of the radio connection reaches up to 1.2Gb/s in the 5GHz band and 574Mb/s in the 2.GHz band. Compliance with the standard also means the possibility of using WPA 3 - the latest transmission encryption method. In the case of wired connectivity, MikroTik hAP ax3 offers 4 10/100/1000Mb/s ports and 1 2.5Gb/s port. In addition to the Ethernet ports, there is also a full-size USB 3.0 port.
Specifications
|
Details |
|
|---|---|
|
Product code |
C53UiG+5HPaxD2HPaxD |
|
Architecture |
ARM 64bit |
|
CPU |
IPQ-6010 |
|
CPU core count |
4 |
|
CPU nominal frequency |
auto (864 - 1800) MHz |
|
Switch chip model |
IPQ-6010 |
|
RouterOS license |
6 |
|
Operating System |
RouterOS v7 |
|
Size of RAM |
1 GB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
MTBF |
Approximately 200'000 hours at 25C |
|
Tested ambient temperature |
-40°C to 70°C |
|
IPsec hardware acceleration |
Yes |
Wireless capabilities
|
Details |
|
|---|---|
|
Wireless 2.4 GHz Max data rate |
574 Mbit/s |
|
Wireless 2.4 GHz number of chains |
2 |
|
Wireless 2.4 GHz standards |
802.11b/g/n/ax |
|
Antenna gain dBi for 2.4 GHz |
3.3 |
|
Wireless 2.4 GHz chip model |
QCN-5022 |
|
Wireless 2.4 GHz generation |
Wi-Fi 6 |
|
Wireless 5 GHz Max data rate |
1200 Mbit/s |
|
Wireless 5 GHz number of chains |
2 |
|
Wireless 5 GHz standards |
802.11a/n/ac/ax |
|
Antenna gain dBi for 5 GHz |
5.5 |
|
Wireless 5 GHz chip model |
QCN-5052 |
|
Wireless 5 GHz generation |
Wi-Fi 6 |
|
WiFi speed |
AX1800 |
Ethernet
|
Details |
|
|---|---|
|
10/100/1000 Ethernet ports |
4 |
|
Number of 1G Ethernet ports with PoE-out |
1 |
|
Number of 2.5G Ethernet ports |
1 |
Peripherals
|
Details |
|
|---|---|
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB 3.0 type A |
|
Max USB current (A) |
1 |
Powering
|
Details |
|
|---|---|
|
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
12-28 V |
|
Max power consumption |
38 W |
|
Max power consumption without attachments |
15 W |
|
Cooling type |
Passive |
|
PoE in |
Passive PoE |
|
PoE in input Voltage |
18-28 V |
PoE-out
|
Details |
|
|---|---|
|
PoE-out ports |
Ether 1 |
|
PoE out |
Passive PoE |
|
Max out per port output (input 18-30 V) |
0.625 A |
|
Max total out (A) |
0.625 A |
|
Total output current |
0.625 |
|
Total output power |
15 |
Certification & Approvals
|
Details |
|
|---|---|
|
Certification |
CE, FCC, IC, EAC, ROHS |
|
IP |
20 |
Other
|
Details |
|
|---|---|
|
CPU temperature monitor |
Yes |
|
Mode button |
Yes |
Wireless specifications
|
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|---|---|
|
1MBit/s |
27 |
-100 |
|
11MBit/s |
27 |
-94 |
|
6MBit/s |
29 |
-96 |
|
54MBit/s |
27 |
-80 |
|
MCS0 |
29 |
-96 |
|
MCS7 |
26 |
-75 |
|
MCS9 |
24 |
-70 |
|
MCS11 |
22 |
-67 |
|
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
|---|---|---|
|
6MBit/s |
28 |
-96 |
|
54MBit/s |
26 |
-80 |
|
MCS0 |
28 |
-96 |
|
MCS7 |
25 |
-75 |
|
MCS9 |
23 |
-70 |
|
MCS11 |
20 |
-67 |
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
