Ubiquiti GNSS Antenna (UACC-GNSS-Antenna)
The Ubiquiti GNSS Antenna is an active GNSS antenna with an integrated LNA amplifier (38 dB gain), designed for time synchronization in EAV-Fiber and EAV-XG-24-PoE devices. It is equipped with a 5-meter RG174 cable with an SMA Male connector.
Accessories and add-ons:
Ubiquiti GNSS Antenna – Active GNSS Antenna (UACC-GNSS-Antenna)
Ubiquiti GNSS Antenna (UACC-GNSS-Antenna) is a compact, active satellite antenna equipped with an integrated low-noise amplifier (LNA). The device is designed to work with the and models, receiving GNSS signals and delivering them to the host device for precise time synchronization.
The antenna operates within the 1559 to 1606 MHz frequency band using right-hand circular polarization (RHCP). The antenna element provides a 2 dBi gain, while the built-in LNA delivers a typical gain of 38 dB. The unit is powered with an operating voltage range of 3.0–5.0V DC (3.3V typical). Connectivity to the host device is established via a factory-integrated 5-meter RG174 coaxial cable (featuring a propagation delay of 25 ns) terminated with a standard SMA Male connector.
Housed in an enclosure measuring ⌀46 x 15 mm and weighing 84 g, the unit is constructed from durable ABS thermoplastic, accompanied by stainless steel mounting hardware. The assembly features an IP67 weatherproof rating, ensuring comprehensive protection against dust and water ingress. The device is built for continuous outdoor operation in harsh environments, withstanding wind speeds of up to 70 m/s and operating reliably across extreme temperatures from -40°C to 85°C. The antenna can be mounted directly onto a wall or attached to a pole with a diameter ranging from 19 to 36 mm.
Key Features
- RF Parameters: 1559–1606 MHz frequency band, RHCP polarization, VSWR rating under 2.0.
- LNA Amplifier: Integrated low-noise amplifier delivering 38 dB typical gain.
- Connectivity: Integrated 5-meter RG174 coaxial cable terminated with an SMA Male connector.
- Environmental Protection: IP67 ingress rating, operating temperature range from -40°C to 85°C.
- Durability: Engineered to withstand high wind speeds (60–70 m/s).
- Mounting Options: Wall mount and pole mount capabilities (pole diameter 19–36 mm).
Technical Specifications
| Frequency Range | 1559–1606 MHz |
| Antenna Gain | 2 dBi |
| LNA Gain | 38 dB typ. |
| Maximum VSWR | < 2.0 |
| Polarization | RHCP (Right-Hand Circular Polarization) |
| RF Connector | SMA Male |
| RF Cable Type | RG174 |
| Cable Length | 5 m (16.4 ft) |
| Delay | 25 ns |
| Supported Voltage Range | 3.0–5.0V DC (typ. 3.3V) |
Other |
|
| Dimensions | ⌀46 x 15 mm (⌀1.8 x 0.6") |
| Weight | 84 g (3 oz) |
| Enclosure Material | Thermoplastic Acrylonitrile Butadiene Styrene (ABS PA-757) |
| Mount Bracket Material | Stainless steel |
| Mounting | Pole mount, wall mount |
| Pole Mount Diameter | ⌀0.75–1.42" (⌀19–36 mm) |
| Ingress Protection | IP67 |
| Wind Survivability | 60–70 m/s (134–157 mph) |
| Wind Loading | 1.5–3.0 kPa |
| Operating Temperature | -40 to 85° C (-40 to 185° F) |
| Manufacturer SKU | UACC-GNSS-Antenna |
|---|---|
| Manufacturer | Ubiquiti |
| GPSR contact | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
-
