Ubiquiti PowerBeam 5AC-620 (PBE-5AC-620)
€192.15 €156.22
In stock
SKU
UBIQUITI-PBE-5AC-620
| Manufacturer SKU | PBE-5AC-620 |
|---|---|
| EAN | 810354022593 |
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 1 |
Ubiquiti PowerBeam 620mm Dish Reflector 5GHz AC 29dBi High-Performance airMAX Bridge, 30km+
 |
UBIQUITI :: PowerBeam 5AC-620 High-Performance airMAX Bridge
UBNT-PBE-5AC-620 supports up to 450+ Mbps real TCP/IP throughput.
UBNT-PBE-5AC-620 supports up to 450+ Mbps real TCP/IP throughput.
Starting with the first-generation
NanoBridge, Ubiquiti Networks
pioneered the all-in-one design for an
airMAX product functioning as a CPE
(Customer Premises Equipment). Now
Ubiquiti Networks launches the latest
generation of CPE, the PowerBeam.
Improved Noise Immunity
The PowerBeam directs RF energy in a
tighter beamwidth. With the focus in
one direction, the PowerBeam blocks
or spatially filters out noise, so noise
immunity is improved. This feature
is especially important in an area
crowded with other RF signals of the
same or similar frequency.
Integrated Design
The PowerBeam models are available in
two form factors:
- All-in-One Design The Ubiquiti Research and Development team combined the radio and antenna to create a more efficient and compact CPE. The PowerBeam gets maximum gain out of the smallest footprint.
- Dish Reflector Design Ubiquiti's InnerFeed technology integrates the radio into the feedhorn of an antenna, so there is no need for a cable. This improves performance because it eliminates cable losses. Providing increased performance from its faster processor and innovative mechanical design at a low cost, the PowerBeam is extremely versatile and cost-effective to deploy
| Gain | 29 dBi |
| Operating Frequency | Worldwide 5170 - 5875 MHz USA 5725 - 5850 MHz |
| Dimensions | 620 x 620 x 386 mm (24.41 x 24.41 x 15.2") |
| Weight | 6.4 kg (14.11 lb) |
| Power Supply | 24V, 0.5A Gigabit PoE |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Max. Power Consumption | 8.5W |
| Wind Loading | 872 N @200 km/h (196 lbf @125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| Signal Strength | LEDs Software-Adjustable to Correspond to Custom RSSI Levels |
| Channel Sizes | PtP Mode: 10/20/30/40/50/60/80 MHz //PtMP Mode: 5/8/10/20/30/40 MHz |
| Polarization | Dual Linear |
| Enclosure | Outdoor UV Stabilized Plastic |
| Mounting | Pole-Mount Kit Included |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Salt Fog Test | IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 |
| Vibration Test | IEC 68-2-6 |
| Temperature Shock Test | IEC 68-2-14 |
| UV Test | IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4 |
| Wind-Driven Rain Test | ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5 |
| Manufacturer SKU | PBE-5AC-620 |
|---|---|
| EAN | 810354022593 |
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 1 |
| GPSR contact | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
