Ubiquiti U7 Pro XG (U7-Pro-XG-B)
| Manufacturer SKU | U7-Pro-XG-B |
|---|---|
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 6 |
Ceiling-mounted 6-stream WiFi 7 AP with 10/5/2.5/1 GbE support.
Accessories and add-ons:
UBIQUITI UniFi U7 Pro XG (U7-Pro-XG-B)
Product Description
The UniFi U7 Pro XG is a ceiling-mounted, tri-band WiFi 7 access point designed for high-density environments. It supports the 2.4 GHz, 5 GHz, and 6 GHz bands, delivering aggregate throughput up to 10.8 Gbps. Equipped with a 10 GbE RJ45 uplink, the U7 Pro XG ensures high-speed connectivity and seamless integration into enterprise networks.
Key Features
- Tri-band WiFi 7 (802.11be) support: 2.4 GHz, 5 GHz, and 6 GHz
- 6 spatial streams (2x2 MIMO per band)
- 10 GbE RJ45 uplink port
- Coverage area up to 140 m² (1,500 ft²)
- Supports over 300 concurrent clients
- Advanced features: MU-MIMO, OFDMA, BSS Transition Management, Fast Roaming
- PoE+ powered (802.3at)
- Fanless design with integrated heatsink
Hardware
| SKU | U7-Pro-XG-B |
| Dimensions | Ø206 x 32.5 mm (Ø8.1 x 1.3") |
| Weight | 750 g (1.7 lb) |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mounting | Ceiling, Wall (Lite Mount Included) |
| Networking Interface | 1x 10 GbE RJ45 port |
| Power Method | PoE+ (802.3at) |
| Max. Power Consumption | 22W |
| Supported Voltage Range | 42.5—57V DC |
| Operating Temperature | -30 to 40°C (-22 to 104°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Certifications | CE, FCC, IC |
Radio
| WiFi Standards | 802.11a/b/g/n/ac/ax/be (WiFi 7) |
| Frequency Bands | 2.4 GHz / 5 GHz / 6 GHz |
| Max. Data Rates | 2.4 GHz: 688 Mbps 5 GHz: 4.3 Gbps 6 GHz: 5.8 Gbps |
| MIMO | 2x2 MU-MIMO per band |
| Antenna Gain | 2.4 GHz: 4 dBi 5 GHz: 5 dBi 6 GHz: 6 dBi |
| Max. TX Power | 2.4 GHz: 23 dBm 5 GHz: 26 dBm 6 GHz: 24 dBm |
| Max. BSSIDs | 8 per radio |
| Channel Bandwidth | 20/40/80/160/240/320 MHz |
Software Features
- Wireless Meshing
- Band Steering
- 802.11v BSS Transition Management
- 802.11r Fast Roaming
- 802.11k Radio Resource Management (RRM)
- Advanced Radio Management
- Passpoint (Hotspot 2.0)
- Captive Portal with Custom Branding
- Voucher and Payment-Based Authentication
- External Portal Server Support
- Password Authentication
- Guest Network Isolation
- Private Pre-Shared Key (PPSK)
- WiFi Speed Limiting
- Client Device Isolation
- WiFi Schedules
- RADIUS over TLS (RadSec)
- Dynamic RADIUS-assigned VLAN
Applications and Compatibility
The U7 Pro XG is ideal for high-density environments such as enterprise offices, conference centers, and educational institutions. Its advanced WiFi 7 capabilities ensure high throughput and low latency for a large number of concurrent clients.
Summary
UBIQUITI's U7 Pro XG offers cutting-edge WiFi 7 performance with tri-band support and a 10 GbE uplink, making it a robust solution for modern enterprise networks requiring high capacity and reliability.
| Manufacturer SKU | U7-Pro-XG-B |
|---|---|
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 6 |
| GPSR contact |
Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
