Ubiquiti Ethernet Surge Protector (ETH-SP)
€12.72 €10.34
Out of stock
SKU
UBIQUITI-ETH-SP
| Manufacturer SKU | ETH-SP |
|---|---|
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 50 |
Ubiquiti Ethernet Surge Protector (ETH-SP)
 |
ETH-SP Ubiquiti Ethernet surge protector with 802.3af PoE support.
 |
Technical Specification
| Dimensions | 91 x 61 x 32.5 mm |
| Weight | 80 g |
| Interface Connections | RJ45 Female Connectors |
| ESD/EMP Protection | Absorbing Transient Current with Response to Surge Voltage from 100V/s to 1kV/us |
| DC Spark-Over Voltage | 90V @ 100V/s |
| Maximum Impulse Spark-over Voltage |
700V @ 1kV/us |
| Discharge Current | 5kA (Maximum) 0.5kA (Normal) |
| Maximum Insulation Resistance |
1G ohm @ 50V |
| Maximum Capacitance | 1.0 pF @ 1 MHz |
| Data Line Protection | RJ45 10/100/1000 Ethernet |
| IEEE 802.3af PoE Support | Yes |
| Shock and Vibration Certification |
ETSI300-019-1.4 Standard |
| Operating Temperature | -30 to 65° C |
| Operating Humidity | 10 to 90% Noncondensing |
| Manufacturer SKU | ETH-SP |
|---|---|
| Manufacturer | Ubiquiti |
| PCS in collective packaging | 50 |
| GPSR contact | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
