Ubiquiti E7 Campus (E7-Campus)
€867.59 €705.36
In stock
SKU
UBIQUITI-E7-CAMPUS
| Manufacturer SKU | E7-Campus |
|---|---|
| Manufacturer | Ubiquiti |
Ubiquiti E7 Campus (E7-Campus) - Enterprise-grade indoor/outdoor access point with 10-stream WiFi 7
Ubiquiti E7 Campus (E7-Campus)
Enterprise-class indoor/outdoor access point with 10-stream WiFi 7 performance, PRISM™ active RF filtering technology, and integrated directional antennas.
- WiFi 7
- 10 spatial streams
- Real-time spectral analysis for enhanced channel selection
- High selectivity PRISM™ RF filtering technology
- Dedicated spectral analyzer radio
- Directional high gain antenna array
- 465 m² (5,000 ft²) coverage
- 1,000+ connected devices
- (1) 10 GbE RJ45 port and (1) GbE RJ45 port for power & data redundancy
- Versatile articulating wall/pole mount for precise position (included), VESA 100x100 compatibility
- Powered using PoE++
Technical Specification
| Mechanical | ||
|---|---|---|
| Dimensions | 250 x 250 x 43.5 mm (9.8 x 9.8 x 1.7") | |
| Weight | 1.8 kg (4 lb) | |
| Enclosure material | UV-stabilized polycarbonate, aluminum alloy | |
| Mount material | Stainless steel (SUS304), galvanized steel (SGCC) | |
| Hardware | ||
| Networking interface | (1) 10 GbE RJ45 port (1) 1 GbE RJ45 port |
|
| Management interface | Ethernet | |
| Power method | PoE++ | |
| Power supply | UniFi PoE switch | |
| Supported voltage range | 42.5—57V DC | |
| Max. power consumption | 43W | |
| Max. TX power 2.4 GHz 5 GHz 6 GHz |
23 dBm 30 dBm 24 dBm / 30* dBm *With 6 GHz Extended Range mode. Available in FCC/IC region only. |
|
| MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) |
|
| Max. data rate 2.4 GHz 5 GHz 6 GHz |
688 Mbps (BW40) 8.6 Gbps (BW240) 11.5 Gbps (BW320) |
|
| Antenna gain 2.4 GHz 5 GHz 6 GHz |
5 dBi 6 dBi 6 dBi |
|
| Antenna | Internal with omni patterns | |
| LEDs | R/G/B | |
| Button | Factory reset | |
| Mounting | Wall/ceiling (Included) | |
| Ambient operating temperature | -30 to 50° C (-22 to 122° F) | |
| Ambient operating humidity | 5 to 95% noncondensing | |
| Certifications | CE, FCC, IC | |
| Software | ||
| WiFi standards | 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7) | |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) | |
| BSSID | 8 per radio | |
| VLAN | 802.1Q | |
| Advanced QoS | Per-user rate limiting | |
| Guest traffic isolation | Supported | |
| Concurrent clients | 1,000+ | |
| Ubiquiti specific features | Dedicated spectral analyzer radio | |
| Supported Data Rates | ||
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11b | 1, 2, 5.5, 11 Mbps | |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11n | 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) | |
| 802.11ac | 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) | |
| 802.11ax (WiFi 6) | 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) | |
| 802.11be (WiFi 7) | 7.3 Mbps to 11.5 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320) | |
| Application Requirements | ||
| UniFi Network | Version 8.6.9 and later | |
| UniFi OS | Version 4.0.20 and later |
| Manufacturer SKU | E7-Campus |
|---|---|
| Manufacturer | Ubiquiti |
| GPSR contact | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
