MikroTik CRS418-8P-8G-2S+RM
Manufacturer SKU | CRS418-8P-8G-2S+RM |
---|---|
Manufacturer | Mikrotik |
PCS in collective packaging | 2 |
CRS418-8P-8G-2S+RM is a 1U rackmount switch with 16 Gigabit Ethernet ports (8 with PoE-out), two 10G SFP+ ports, a quad-core 2.2 GHz CPU, dual redundant power inputs, and RouterOS v7 with Layer 3 hardware offloading and routing support.
MikroTik CRS418-8P-8G-2S+RM (CRS418-8P-8G-2S+RM)
Product Description
The CRS418-8P-8G-2S+RM is a 1U rackmount switch offering a complete solution for small and medium-sized networks that require efficient switching, routing, and PoE functionality in a single device. It features 16 Gigabit Ethernet ports – including 8 PoE-out ports (802.3af/at and 24V Passive) – plus 2× 10G SFP+ uplink cages for high-speed connectivity. Powered by a quad-core 2.2 GHz ARM processor, this device delivers reliable performance even under routing workloads.
With RouterOS v7 (license level 5) and Layer 3 hardware offloading, the CRS418 supports VLAN segmentation, inter-VLAN routing, traffic management, and SNMP monitoring. Its redundant AC power inputs ensure higher availability, while the USB 3.0 port and a dedicated management port provide flexible configuration options.
This switch is ideal for powering access points, VoIP phones, IP cameras, and more – all while serving as a central routing unit for hybrid Layer 2/3 network environments. The compact form factor and comprehensive feature set make it a robust choice for modern office deployments.
Main Features
- 16× Gigabit Ethernet ports (8× PoE-out ports)
- 2× 10G SFP+ uplink ports
- Quad-core 2.2 GHz ARM processor
- Layer 3 hardware offloading with RouterOS v7
- USB 3.0 port and Gigabit management port with direct CPU access
- Redundant AC power inputs with 150 W total PoE output




Technical Specification
Mechanical
Dimensions | 443 × 230 × 44 mm |
Operating temperature | -20°C to +70°C |
Hardware
Product code | CRS418-8P-8G-2S+RM |
CPU | Quad-Core IPQ-8072 2208 MHz |
CPU architecture | ARM 64bit |
RAM | 1 GB DDR3L |
Storage | 128 MB NAND |
Operating system | RouterOS v7, License level 5 |
Networking interfaces | 17× 1G Ethernet ports, 2× 10G SFP+ |
USB port | 1× USB 3.0 Type-A |
Switch chip model | 98DX226S |
Management port | Dedicated 1G port (direct CPU access) |
Power
Number of AC inputs | 2 |
AC input range | 100–240 V |
Nominal voltage | 55 V |
Nominal current | 4.5 A |
PoE-Out standard | 802.3af/at and 24V Passive |
PoE-Out ports | Ether9 to Ether16 |
Max output per port (<30V) | 1.1 A |
Max output per port (>30V) | 0.55 A |
Total PoE output power | 150 W |
Max power consumption | 215 W |
Power consumption (no attachments) | 28 W |
Usage and Compatibility
Designed for small and mid-sized business networks, the CRS418-8P-8G-2S+RM is perfect for PoE deployments, fiber uplinks, NAS connectivity, and routing scenarios. Its hybrid Layer 2/3 functionality makes it ideal for modern enterprise setups.
Summary
MikroTik CRS418-8P-8G-2S+RM merges switching, routing, and PoE management in a single compact unit. With high processing power, rich port variety, and dual redundant power, it ensures stability and control in critical environments.
