Mikrotik SXT SA5 (RBSXTG-5HPnD-SAr2)
89,63 € 72,87 €
Disponibile
SKU
RTB-RBSXTG-5HND-SAR2
| SKU del produttore | RBSXTG-5HPnD-SAr2 |
|---|---|
| Produttore | Mikrotik |
| In un imballaggio collettivo | 20 |
SXT SA5 (RBSXTG-5HPnD-SAr2)
 |
SXTG-5HPnD-SAr2 is a low cost, high speed 5GHz outdoor wireless sector access point. It has a ninety degree antenna to provide a wider coverage than our previous SXT units.
Complete with a ready to mount enclosure and built-in 14dBi antenna, the package contains everything you need to set it up in a matter of minutes.
Main Features
- 14dBi, dual chain, 90° built-in antenna
- 10/100/1000Mbps Ethernet interface
- 10kV ESD protection on RF port
 |
Technical Specification
| CPU | AR9344 600MHz CPU |
| Memory | 64MB DDR SDRAM onboard memory |
| Ethernet | 10/100/1000 (Gigabit) Ethernet port |
| Wireless | Onboard dual chain 5GHz 802.11a/n .10kV ESD protection on RF port |
| Extras | Reset switch, beeper, USB 2.0 port, voltage and temperature monitors |
| LEDs | Power LED, Ethernet LED, 5 wireless signal LED |
| Power | Power over Ethernet: 8-30V DC. Packaged with 24V DC 0.8A PSU and passive PoE injector |
| Dimensions | 140×140×56mm. Weight without packaging, adapters and cables: 265g |
| Power consumption | Up to 7W |
| Operating Temp | -30°C .. +80°C |
| License | Level4 license (CPE, PtP or AP as sector) |
| Package contains | SXT wireless device with integrated antenna, pole mounting bracket, mounting ring, PoE injector, power adapter, quick setup guide |
| Certifications | FCC, CE, ROHS |
TX Power/RX Sensitivity table (2x2 MIMO)
| TX/RX at MCS0 | 30dBm / -95dBm |
| TX/RX at MCS7 | 26dBm / -73dBm |
| TX/RX at 6Mbit | 30dBm / -96dBm |
| TX/RX at 54Mbit | 27dBm / -80dBm |
| Antenna 90 deg, -35dB port to port isolation, 14dBi gain | |
