Mikrotik SXT SA5 (RBSXTG-5HPnD-SAr2)
91,36 € 74,28 €
Disponibile
SKU
RTB-RBSXTG-5HND-SAR2
| SKU del produttore | RBSXTG-5HPnD-SAr2 |
|---|---|
| Produttore | Mikrotik |
| In un imballaggio collettivo | 20 |
SXT SA5 (RBSXTG-5HPnD-SAr2)
 |
SXTG-5HPnD-SAr2 is a low cost, high speed 5GHz outdoor wireless sector access point. It has a ninety degree antenna to provide a wider coverage than our previous SXT units.
Complete with a ready to mount enclosure and built-in 14dBi antenna, the package contains everything you need to set it up in a matter of minutes.
Main Features
- 14dBi, dual chain, 90° built-in antenna
- 10/100/1000Mbps Ethernet interface
- 10kV ESD protection on RF port
 |
Technical Specification
| CPU | AR9344 600MHz CPU |
| Memoria | 64MB DDR SDRAM onboard memory |
| Ethernet | 10/100/1000 (Gigabit) Ethernet port |
| Senza fili | Onboard dual chain 5GHz 802.11a/n .10kV ESD protection on RF port |
| Extra | Reset switch, beeper, USB 2.0 port, voltage and temperature monitors |
| LED | Power LED, Ethernet LED, 5 wireless signal LED |
| Potenza | Power over Ethernet: 8-30V DC. Packaged with 24V DC 0.8A PSU and passive PoE injector |
| Dimensioni | 140×140×56mm. Weight without packaging, adapters and cables: 265g |
| Consumo di energia | Up to 7W |
| Temperatura di esercizio | -30°C .. +80°C |
| Licenza | Level4 license (CPE, PtP or AP as sector) |
| La confezione contiene | SXT wireless device with integrated antenna, pole mounting bracket, mounting ring, PoE injector, power adapter, quick setup guide |
| Certificazioni | FCC, CE, ROHS |
TX Power/RX Sensitivity table (2x2 MIMO)
| TX/RX su MCS0 | 30dBm / -95dBm |
| TX/RX su MCS7 | 26dBm / -73dBm |
| TX/RX a 6Mbit | 30dBm / -96dBm |
| TX/RX a 54Mbit | 27dBm / -80dBm |
| Antenna a 90 gradi, isolamento da porta a porta -35 dB, guadagno 14 dBi | |
| SKU del produttore | RBSXTG-5HPnD-SAr2 |
|---|---|
| Produttore | Mikrotik |
| In un imballaggio collettivo | 20 |
| GPSR contatto | Mikrotikls SIA Unijas iela 2, LV-1039 Riga, Latvia support@mikrotik.com |
