Ubiquiti U7 Professional (U7-Pro)
195,64 € 159,06 €
Disponible
SKU
UBIQUITI-U7-PRO
| SKU del fabricante | U7-PRO |
|---|---|
| EAN | 810084693650 |
| Fabricante | Ubiquiti |
| Piezas en embalaje colectivo | 5 |
Ubiquiti U7 Professional (U7-Pro) - Ceiling-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support for interference-free WiFi in demanding, large-scale environments.
Ubiquiti U7 Professional (U7-Pro)
The Access Point WiFi 7 Pro (U7-Pro) is a high-performance, tri-band WiFi 7 access point ideal for home and office use. Ceiling-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support for interference-free WiFi in demanding, large-scale environments. The U7-Pro is capable of reaching an aggregate throughput rate up to 9,8 Gbps with its 6 GHz (2x2 MIMO), 5 GHz (2x2 MIMO) and 2.4 GHz (2x2 MIMO) bands.
Main Features:
- WiFi 7 tri-radio with 6 GHz
- 6 spatial streams
- 140 m² (1,500 ft²) coverage
- 300+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
Technical specification:
| Mecánica | ||
|---|---|---|
| Dimensiones | Ø206 x 46 mm (Ø8.1 x 1.8") | |
| Peso | 680 g (1.5 lb) | |
| Materiales de cerramiento | Polycarbonate, metal | |
| Material de montaje | Mounting bracket: stainless steel (SUS304) Backing plate: galvanized steel (SGCC) |
|
| Hardware | ||
| Interfaz de red | (1) 2.5 GbE RJ45 port | |
| Interfaz de gestión | Ethernet | |
| Método Power | PoE+ | |
| Alimentación | UniFi PoE switch | |
| Rango de tensión soportado | 44—57V DC | |
| Consumo máximo | 21W | |
| Máx. Potencia TX 2.4 GHz 5 GHz 6 GHz |
22 dBm 26 dBm 23 dBm |
|
| MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 2 x 2 2 x 2 |
|
| Tasa de rendimiento 2.4 GHz 5 GHz 6 GHz |
688 Mbps 2882 Mbps 5765 Mbps |
|
| Ganancia de la antena 2.4 GHz 5 GHz 6 GHz |
4 dBi 6 dBi 5.8 dBi |
|
| LEDs | White/blue | |
| Botón | Factory reset | |
| Montaje | Wall/ceiling (Included) | |
| Temperatura de funcionamiento | -30 to 60° C (-22 to 140° F) | |
| Humedad de funcionamiento | 5 to 95% noncondensing | |
| Certificaciones | CE, FCC, IC | |
| Software | ||
| Normas WiFi | 802.11a/b/g/n/ac/ax/be | |
| Seguridad inalámbrica | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) | |
| BSSID | 8 per radio | |
| VLAN | 802.1Q | |
| QoS avanzada | Per-user rate limiting | |
| Aislamiento del tráfico de invitados | Supported | |
| Clientes simultáneos | 300+ | |
| Velocidades de datos admitidas | ||
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11b | 1, 2, 5.5, 11 Mbps | |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) | |
| 802.11ac (WiFi 5) | 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) | |
| 802.11ax (WiFi 6) | 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) | |
| 802.11be (WiFi 7) | 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320) | |
| Requisitos de solicitud | ||
| Red UniFi | Version 8.0.7 and later | |
| Sistema operativo UniFi | Version 3.2 and later |
Más opciones:
| SKU del fabricante | U7-PRO |
|---|---|
| EAN | 810084693650 |
| Fabricante | Ubiquiti |
| Piezas en embalaje colectivo | 5 |
| GPSR contacto | Ubiquiti International Holding B.V. Ekkersrijt 3102, 5692 CC Son en Breugel support@ui.com |
