Ubiquiti - Enterprise Campus 48 PoE (ECS-48-PoE)
| SKU del fabricante | ECS-48-PoE |
|---|---|
| Fabricante | Ubiquiti |
48-port L3 switch with PoE+, 4 × 10G SFP+ uplinks, redundant power supplies, Etherlighting™ support, and 1.3" touchscreen for local monitoring.
Accesorios y complementos:
Ubiquiti - Enterprise Campus 48 PoE (ECS-48-PoE)
48-port L3 switch with 48 × 2.5 GbE ports, PoE+++ support, and four 25G SFP28 uplinks. Equipped with two hot-swappable 600 W AC power modules, four replaceable cooling fans, and a 1.3-inch touchscreen for local monitoring.
Product Description
Enterprise Campus 48 PoE is a managed L3 network switch designed for 19" rack mounting (1U). It provides 48 RJ45 ports with PoE+++ capability (48 × 2.5 GbE) and 4 SFP28 25 GbE uplink ports. The switch delivers a switching capacity of 880 Gbps and a forwarding rate of up to 654 Mpps. Each PoE port supports up to 90 W power output.
The device includes two hot-swappable 600 W AC power modules operating in Shared or Redundant mode, and four replaceable cooling fans. The PoE power budget is up to 2000 W in Shared mode and 900 W in Redundant mode. The switch supports Etherlighting™, a visual indicator system for PoE consumption.
It also features a 1.3" touchscreen display for local diagnostics and monitoring. The full-depth enclosure is made of SGCC steel. Operating temperature ranges from -5 °C to 40 °C, and humidity from 10% to 90% (non-condensing).
Key Features
- 48-port L3 switch: 48 × 2.5 GbE RJ45 ports with PoE+++.
- 4 SFP28 uplink ports: supports 1G/10G/25G optical connections.
- PoE+++ support: up to 90 W power per RJ45 port.
- Hot-swappable power modules: 2 × 600 W AC with Shared or Redundant operation modes.
- Etherlighting™: visual indication of PoE power usage per port.
- LCM display: 1.3" touchscreen for local management and diagnostics.
Technical Specifications
Mechanical
| Dimensions | 442.4 × 43.7 × 496 mm |
| Weight (without rack mounts) | 10.55 kg |
| Weight (with rack mounts) | 10.65 kg |
| Enclosure Material | SGCC steel |
| Mounting | Standard 19" rack, 1U full-depth |
Network Interfaces
| Ethernet Ports | 48 × 2.5G RJ45 (PoE+++) |
| SFP Ports | 4 × 25G SFP28 |
| VLANs Supported | Up to 1,000 |
| MAC Table Size | 128,000 entries |
| ARP Table Size | 128,000 entries |
| IPv4 Routes | 256,000 |
Performance
| Switching Capacity | 880 Gbps |
| Non-blocking Throughput | 440 Gbps |
| Forwarding Rate | 654 Mpps |
Power
| Power Input | 2 × 100–240 V AC, 50/60 Hz |
| Power Supply Modules | 2 × AC/DC 600 W (hot-swappable) |
| Power Consumption (without PoE) | 1.50 W |
| Power Consumption (with full PoE load) | Up to 3000 W |
| PoE Budget (Shared Mode) | 2000 W |
| PoE Budget (Redundant Mode) | 900 W |
| Max Power per Port | 90 W |
| Etherlighting™ | Supported |
Environmental
| Operating Temperature | -5 °C to 40 °C |
| Operating Humidity | 10% to 90% (non-condensing) |
| ESD/EMP Protection | Air ±30 kV, Contact ±30 kV |
Management and Compliance
| Display | 1.3" touchscreen (LCM) |
| Software Requirements | UniFi Network version 9.0.114 or newer |
| Certifications | CE, FCC, IC, NDAA compliant |
Summary
Enterprise Campus 48 PoE is an L3 switch with 2.5G RJ45 ports, 25G SFP28 uplinks, PoE+++ support, redundant power modules, and integrated Etherlighting™. Suitable for enterprise campus networks with high power and bandwidth requirements.
