Ubiquiti E7 Audience (E7-Audience)
2.118,58 € 1.722,42 €
Disponible
SKU
UBIQUITI-E7-AUDIENCE
| SKU del fabricante | E7-Audience |
|---|---|
| Fabricante | Ubiquiti |
Ubiquiti E7 Audience (E7-Audience) - Punto de acceso interior de nivel empresarial diseñado para entornos de alta densidad
Ubiquiti E7 Audience (E7-Audience)
Punto de acceso de interior de clase empresarial para entornos de alta potencia con 12 transmisiones WiFi 7 de 5 GHz y 6 GHz, enlace ascendente de 10 GbE y un puerto GbE para transferencia de datos redundante.
- WiFi 7 con compatibilidad con banda de 6 GHz
- Juego de radio de 12 transmisiones
- Selector de canal con analizador de espectro de RF
- Filtro de alta selectividad RF PRISM™ utilizado
- Analizador de espectro de RF dedicado
- La antena de formación de haz direccional seleccionable (15 dBi, 50° o 11 dBi, 90°) permite una optimización especializada
- Cobertura de espacio abierto de más de 465 m² (más de 5000 ft²)
- Capacidad para implementar más de 1500 dispositivos
- (1) puerto RJ45 de 10 GbE y (1) puerto RJ45 de GbE para alimentación y transmisión de datos redundante
- Montaje universal en pared y poste
- Fuente de alimentación PoE++
Especificaciones técnicas
| Mechanical | |
|---|---|
| Dimensions | Device: 474.1 x 239.4 x 42.2 mm (18.7 x 9.4 x 1.7") Bracket: 150.4 x 113.6 x 125 mm (5.9 x 4.5 x 4.9") |
| Weight | Without mount: 3.2 kg (7.1 lb) With mount: 4.2 kg (9.3 lb) |
| Enclosure material | Aluminum alloy, UV-stabilized polycarbonate |
| Mount material | Aluminum alloy |
| Pole mount diameter | 1~3" (25~76 mm) on pipe outer diameter |
| Hardware | |
| Networking interface | (1) 10 GbE RJ45 port (1) GbE RJ45 port |
| Management interface | Ethernet |
| Power method | PoE++ |
| Max. power consumption | 51W |
| Supported voltage range | 42.5—57V DC |
| Max. TX power 2.4 GHz 5 GHz 6 GHz |
– 30 dBm Low / High band: 30 dBm* *Depends on regulatory region. |
| MIMO 2.4 GHz 5 GHz 6 GHz |
– 4 x 4 (DL/UL MU-MIMO) Low / High band: 4 x 4 (DL/UL MU-MIMO) |
| Max. data rate 2.4 GHz 5 GHz 6 GHz |
– 8.6 Gbps (BW240) Low / High band: 11.5 Gbps (BW320) |
| Antenna gain 2.4 GHz 5 GHz 6 GHz |
– Small cell: 15 dBi / Large cell: 11 dBi Small cell: 15 dBi / Large cell: 11 dBi |
| Antenna beamwidth Small cell Large cell |
50° 90° |
| Antenna | Internal with directional patterns |
| LEDs | R/G/B |
| Button | Factory reset |
| Mounting | VESA-compatible mount, pole/wall (Brackets included) |
| Ambient operating temperature | -40 to 60° C (-40 to 140° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE |
| Software | |
| WiFi standards | 802.11 a/b/g/n/ac/ax/be |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Concurrent clients | 1,500+ |
| Ubiquiti specific features | High selectivity PRISM™ RF filtering technology Dedicated spectral analyzer radio |
| Supported Data Rates | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11g | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
| 802.11ac | 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
| 802.11ax | 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
| 802.11be | 7.3 Mbps to 11.5 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320) |
| SKU del fabricante | E7-Audience |
|---|---|
| Fabricante | Ubiquiti |
